Commando HD Grade 1 Commercial Rim Exit Device Push Bar For Metal Doors

Commando exit devices are second to none. These exit devices earned their name from the noticeable durability and long lasting life span they had on some of the busiest and most frequently used commercial exit doors. Commando push bar exit devices are safe and reliable, perfect for any rear exit door in a restaurant, office, warehouse, or other commercial building. These commercial grade panic bars are easy to depress allowing anyone to safely exit the building. The Commando exit device can easily be surface mounted to any commercial wood or steel door. It is also very easy to retrofit or replace an existing defective panic bar with the Commando exit device.

Commando Exit Device Features

• The Commando push bar body is constructed from heavy duty extruded aluminum preventing it from bending like other exit devices. The push pad and end caps are made from stainless steel which also prevents the exit device from any potential damage or impact.
• High quality and durable lock chassis. Where many exit devices fail under abusive conditions, the Commando excels. The panic rated model lock chassis is constructed from a non ferrous alloy while the fire rated model lock chassis made from steel.
• The Commando exit device includes the dogging feature standard for panic rated devices. Fire rated models feature no dogging.
• The Commando exit device is a non handed universal design and can be used on either a left hand or right hand door.
• The Commando exit device includes both wood and machine screws so the push bar can be installed on a commercial wood or hollow metal steel door. Fire rated models include thru bolts.

Commando Exit Device Certifications

• The Commando exit device is certified ANSI A156.3, GRADE 1
• The Commando exit device Conforms & Meets ADA Regulations.
• The Commando panic rated exit device is UL Listed. The Commando fire rated exit device is certified ULC10C for Fire Exit Hardware 3 hours, UBC 7-2-1997 codes.
• The Commando exit device is (A) label rating on pairs of doors up to 8'0" x 8'0" swinging in same or opposite directions.

Commando Heavy Duty Exit Device Specifications

• The Commando neutral push pad projection: 3-5/8"
• The Commando depressed push pad projection: 2-7/8"
• The Commando center case dimensions: 8-1/16" x 2-3/4" x 2-1/2"

Commando Heavy Duty Exit Device Cut Down Details

• The Commando exit device can be cut down to meet non standard door sizes.
• The actual exit device size for a 36" wide door is a 32" exit device length. It can be field cut down up to 6" on the non push pad side in order to mount on door sizes 30" to 36" wide.
• The actual exit device size for a 48" wide door is a 44" exit device length. It can be field cut down up to 10" on the non push pad side in order to mount on door sizes 38" to 48" wide.
