Crash Bar Panic Exit Device and Escutcheon Handle For Commercial Wood and Hollow Metal Doors

Commando crash bar exit devices are second to none. Crash bar exit devices or cross bar exit devices, are often chosen for their reliability and easy of use. Just the design and look of this type of crash bar on a commercial door signals all pedestrians that this door is an exit door. Commando crash bar exit devices are often seen on gymnasium doors or school exit doors. The Commando crash bar is device is reliable, safe, and a great alternative to the common touch pad panic exit device.

Commando Outside Escutcheon Entrance Handle Features

• 16" Height x 3-1/2" Wide
• 1-3/4" Projection
• 6 pin Schlage C Keyway
• For 1-3/4" Thick Doors
• Entrance Function - Rigid Entrance, Key Locks or Unlocks Escutcheon Trim, operates as classroom function ANSI 08

Commando Crash Bar Exit Device Features

• The Commando crash bar exit device is for standard doors that are 1 3/4" thick.
• The Commando crash bar exit device requires atleast a 4-1/2" minimum stile width for a single or double door application using the standard strike with a pull lever, thumbpiece or escutcheon trims.
• The Commando crash bar features a heavy duty chassis with a non-ferrous alloy cover to prevent damage in even the most abusive door environments.
• The Commando crash bar chassis is designed to cover the standard 161 lock prep used on hollow metal or commercial wood doors.
• The Commando crash bar exit device is furnished with wood and machine screws for either hollow metal door or wood doors.
• The Commando crash bar exit device is handed (left hand reverse or right hand reverse), please refer to handing diagram.
• The Commando crash bar exit device latch bolt is 100% stainless steel with a 3/4" throw ensuring optimum security.
• Unlike competitor brands, the Commando crash bar exit device features a stainless steel spring ensuring a long product life span.
• The Commando crash bar exit device uses a roller type rim strike that is surface mounted for easy and fast installation or adjustment.
• The Commando crash bar exit device comes standard with an Allen key dogging feature allowing the exit device to stay unlatched. This is a great feature for hours during the day where peak foot traffic is present.
• The Commando crash bar exit device is available in US26D satin chrome or dark bronze.

Commando Crash Bar Exit Device Certifications

• The Commando crash bar exit device is UL and ULC Listed, ensuring high quality and safety.
• The Commando crash bar exit device is ANSI Standard – A156.3, Grade 2 tested for over 250,000 cycles, ensuring that it is a durable and reliable product.

Commando Crash Bar Exit Device Specifications

• The Command touch bar height to finished floor is 36-1/2" at center.
• The Commando latch height to finished floor is 41".
• The Commando touch bar projection is: Neutral is 4-3/4"; Depressed is 3".
• The Commando crash bar main case is 8-1/2" x 2-5/8" x 2".
• The Commando end case is 4-7/8" x 2-1/8".
• The Commando actual cross bar length is 30" for 36" wide door or 42" for 48" wide door.
• The Commando cross bar is 1" Diameter Steel and 0.058" thick.
